This stone arch tunnel is one of four existing tunnels at Westminster Junction

St. Paul, Ramsey County, Minnesota

Owner: Union Pacific Railroad

Status: In Use

Built 1889

by

Unknown

for

Chicago, St. Paul, Minneapolis & Omaha Railway and Northern Pacific Railway

Design:
267' stone arch tunnel

Description:
Stone arch tunnel over BNSF Railway

Significance:

This concrete arch bridge is a unique grade separation near Como Park

St. Paul, Ramsey County, Minnesota

Owner: BNSF Railway

Status: Open to Traffic

Built 1908

by

Northern Pacific Railway

Design:
50' closed spandrel concrete arch

Description:
Closed spandrel concrete arch bridge over Lexington Parkway

Significance:

This attractive steel stringer and concrete arch bridge carries the Gateway State Trail over Wheelock Parkway

St. Paul, Ramsey County, Minnesota

Owner: Minnesota Department of Natural Resources

Status: Open to Trail Traffic

Built 1938

by

Unknown

for

Minneapolis, St. Paul & Sault Ste. Marie Railway

Design:
40' steel stringer and concrete slab

Description:
Steel stringer bridge over Wheelock Parkway

Significance:

This deck plate girder bridge was built in 1889 and later strengthened in 1926

St. Paul, Ramsey County, Minnesota

Owner: BNSF Railway

Status: Open to Traffic

Built 1889

by

Unknown

for

Northern Pacific Railway

Design:
45' deck plate girder with helper pier

Description:
Deck plate girder bridge over 4th Street

Significance:

This standard steel stringer bridge crosses Water Street near the swing bridge across the Mississippi River

St. Paul, Ramsey County, Minnesota

Owner: Union Pacific Railroad

Status: In Use

Built c. 1905

by

Unknown

for

Chicago, St. Paul, Minneapolis & Omaha Railway

Design:
26' steel stringer and trestle

Description:
Steel stringer bridge over Water Street

Significance:

This deck plate girder bridge crosses I-35E south of St. Clair Avenue

St. Paul, Ramsey County, Minnesota

Owner: Canadian Pacific Kansas City Limited

Status: In Use

Built 1966

by

Unknown

for

Chicago, Milwaukee, St. Paul & Pacific Railroad

Design:
2-95' deck plate girders

Description:
Deck plate girder bridge over Interstate 35E

Significance:

This stone arch tunnel is one of four existing tunnels at Westminster Junction

St. Paul, Ramsey County, Minnesota

Owner: Union Pacific Railroad

Status: In Use

Built 1885 and reconstructed 1922

by

Unknown

for

Chicago, St. Paul, Minneapolis & Omaha Railway and Northern Pacific Railway

Design:
30' stone and brick arch tunnel

Description:
Stone arch tunnel over BNSF Railway

Significance:

This large through plate girder bridge cairres the Gateway Trail over Westminster Street

St. Paul, Ramsey County, Minnesota

Owner: Minnesota Department of Natural Resources (DNR)

Status: Replaced by a new bridge

Built 1919

by

Wisconsin Bridge & Iron Company of North Milwaukee, Wisconsin

for

Minneapolis, St. Paul & Sault Ste. Marie Railway

Design:
95' skewed through plate girder and trestle

Description:
Through plate girder bridge over Westminster Street

Significance:

This through plate girder bridge crosses Johnson Parkway south of Phalen Boulevard

St. Paul, Ramsey County, Minnesota

Owner: Union Pacific Railroad

Status: In Use

Built 1906

by

American Bridge Company of New York and James McClure of St. Paul, Minnesota

for

Chicago, St. Paul, Minneapolis & Omaha Railway

Design:
47' through plate girder and 2-14' steel stringers

Description:
Through plate girder bridge over Johnson Parkway

Significance:

This helicoidal stone arch bridge carries East Seventh Street over the Bruce Vento Regional Trail

St. Paul, Ramsey County, Minnesota

Owner: City of St. Paul

Status: Open to Traffic

Built 1884

by

McArthur Brothers of Chicago, Illinois and William Albert Truesdell

for

St. Paul and Duluth Railroad

Design:
2 span skewed helicoidal stone arch

Description:
Helicoidal stone arch bridge over Bruce Vento Regional Trail on East Seventh Street

Significance:
