Railroad Bridges in Kane County , Illinois
Kane County is located in northeast Illinois, and is one of the outer counties of the Chicagoland Area. The seat is Geneva, while the largest city is Aurora.
Random Bridges
BNSF IL Route 47 Bridge (Sugar Grove)
/164475.JPG)
BNSF IL Route 47 Bridge (Sugar Grove)
(Chicago, Burlington and Quincy Railroad Bridge #44.68)
This steel stringer bridge carries the former Chicago, Burlington & Quincy Railroad over US Route 30/Illinois Route 47 in Sugar Grove
Sugar Grove, Kane County, Illinois
Owner: BNSF Railway
Status: In Use, Scheduled For Replacement
Built 1937
by
Worden-Allen Company of Milwaukee, Wisconsin and Unknown
for
Chicago, Burlington & Quincy Railroad
Design:
1-48' and 2-29' steel stringer
Description:
Steel stringer bridge over US Route 30/Illinois Route 47
Significance:
BNSF River Street Bridge (Aurora)
/129014.JPG)
BNSF River Street Bridge (Aurora)
(Chicago, Burlington and Quincy Railroad Bridge #38.48)
This concrete deck girder bridge carries the former Chicago, Burlington & Quincy Railroad over River Street in Aurora
Owner: BNSF Railway
Status: In Use
Built 1921
by
Chicago, Burlington & Quincy Railroad
Design:
2-36' concrete deck girder and 2-13' concrete slab
Description:
Concrete deck girder bridge over River Street
Significance:
AE&FRE Unnamed Creek Culvert (South)
/132104.JPG)
AE&FRE Unnamed Creek Culvert (South)
This small concrete box culvert carries the former Aurora, Elgin & Fox River Electric Company over an unnamed creek in South Elgin
South Elgin, Kane County, Illinois
Owner: Fox River Trolley Museum
Status: In Use
Built c. 1905
by
Unknown
for
Elgin, Aurora & Southern Traction Company
Design:
8' concrete box culvert
Description:
Concrete box culvert over unnamed creek
Significance:
UP Chicago Street Bridge (Elgin)
/128134.JPG)
UP Chicago Street Bridge (Elgin)
(Chicago & North Western Railway Bridge #337)
This through plate girder bridge carries the former Chicago & North Western Railway over Chicago Street in Elgin
Owner: Union Pacific Railroad
Status: In Use
Built 1890
by
Unknown
for
Chicago & North Western Railway
Design:
42' deck plate girder, and 17' and 18' deck plate girder
Description:
Through plate girder bridge over Chicago Street
Significance:
Great Western Trail - IL Route 47 Bridge
Great Western Trail - IL Route 47 Bridge
(Chicago Great Western Railway Bridge #44.76)
This deck plate girder bridge carries the Great Western Trail over Illinois Route 47 in Lily Lake
Lily Lake, Kane County, Illinois
Owner: Forest Preserve District of Kane County
Status: Open to Pedestrian Traffic
Built 1939
by
Lakeside Bridge Company of North Milwaukee, Wisconsin and Cephas Williams Construction Company of Streator, Illinois
for
Chicago Great Western Railway
Design:
67' deck plate girder
Description:
Deck plate girder bridge over Illinois Route 47
Significance:
Great Western Trail - Culvert #46.80
Great Western Trail - Culvert #46.80
(Chicago Great Western Railway Bridge #46.80)
This concrete encased beam bridge carries the Great Western Trail over a farm entrance along Illinois Route 64 east of Virgil
Owner: Forest Preserve District of Kane County
Status: Open to Pedestrian Traffic
Built 1910
by
Unknown
for
Chicago Great Western Railway
Design:
11' concrete encased beam
Description:
Concrete encased beam bridge over farm entrance
Significance:
Hurds Island Railroad Bridge (West)
/129048.JPG)
Hurds Island Railroad Bridge (West)
(Chicago, Burlington and Quincy Railroad Bridge #38.44)
This large concrete arch bridge is the eastern of two structures carrying the former Chicago, Burlington & Quincy Railroad over the Fox River at Hurds Island
Owner: BNSF Railway
Status: In Use
Built 1920
by
Chicago, Burlington & Quincy Railroad
Design:
3-65' open spandrel concrete arch
Description:
Open spandrel concrete arch bridge over Fox River
Significance:
South Elgin Railroad Crossing
South Elgin Railroad Crossing
(Chicago & North Western Railway Bridge #316)
This historic pony truss bridge carries the former Chicago & North Western Railway over the former Illinois Central Railroad near Stearns Road in South Elgin
South Elgin, Kane County, Illinois
Owner: Union Pacific Railroad
Status: In Use
Built 1887
by
Union Bridge Company of Buffalo, New York and Unknown
for
Chicago & North Western Railway
Design:
87' double intersection Warren pony truss
Description:
Double intersection Warren pony truss bridge over Canadian National Railway
Significance:
CPKC Elgin & Belvidere Electric Bridge
CPKC Elgin & Belvidere Electric Bridge
(Chicago, Milwaukee & St. Paul Railway Bridge #Z-119 1/2)
This concrete box culvert once carried the Chicago, Milwaukee & St. Paul Railway over the Elgin & Belvidere Electric Company on the west side of Elgin
Owner: Canadian Pacific Kansas City Limited
Status: In Use
Built 1906
by
Chicago, Milwaukee & St. Paul Railway
Design:
14' concrete box culvert
Description:
Concrete box culvert over abandoned Elgin & Belvidere Electric Company
Significance:
UP Fox River Bridge (Elgin)
/145018.JPG)
UP Fox River Bridge (Elgin)
(Chicago & North Western Railway Bridge #333)
This deck plate girder bridge is the western of two parallel railroad bridges across the Fox River at this location
Owner: Union Pacific Railroad
Status: In Use
Built 1912
by
American Bridge Company of New York
for
Chicago & North Western Railway
Design:
2-80' and 3-75' deck plate girders
Description:
Deck plate girder bridge over Fox River
Significance:
