Railroad Bridges in Kane County, Illinois
Kane County is located in northeast Illinois, and is one of the outer counties of the Chicagoland Area. The seat is Geneva, while the largest city is Aurora.
Random Bridges
Fox River Trail - Unnamed Creek Culvert (Elgin, Middle)
Fox River Trail - Unnamed Creek Culvert (Elgin, Middle)
This concrete box culvert carries the Fox River Trail over an unnamed creek near Wellington Avenue in Elgin
Owner: Forest Preserve District of Kane County
Status: Open to Pedestrian Traffic
Built 1901
by
Cleveland Construction Company of Akron, Ohio
for
Aurora, Elgin & Chicago Railway
Design:
5' concrete box culvert
Description:
Concrete box culvert over unnamed creek
Significance:
UP Fox River Bridge (Elgin)
/145018.JPG)
UP Fox River Bridge (Elgin)
(Chicago & North Western Railway Bridge #333)
This deck plate girder bridge is the western of two parallel railroad bridges across the Fox River at this location
Owner: Union Pacific Railroad
Status: In Use
Built 1912
by
American Bridge Company of New York
for
Chicago & North Western Railway
Design:
2-80' and 3-75' deck plate girders
Description:
Deck plate girder bridge over Fox River
Significance:
BNSF East Branch Big Rock Creek Bridge
BNSF East Branch Big Rock Creek Bridge
(Chicago, Burlington and Quincy Railroad Bridge #51.44)
This deck plate girder bridge carries the former Chicago, Burlington & Quincy Railroad over the East Branch of Big Rock Creek west of Big Rock
Big Rock, Kane County, Illinois
Owner: BNSF Railway
Status: In Use
Built 1960 using spans fabricated 1911 and 1926
by
Pennsylvania Steel Company of Steelton, Pennsylvania and Unknown
for
Chicago, Burlington & Quincy Railroad
Design:
75' and 2-39' deck plate girders
Description:
Deck plate girder bridge over East Branch Big Rock Creek
Significance:
BNSF Batavia Creek Culvert
BNSF Batavia Creek Culvert
(Chicago, Burlington and Quincy Railroad Bridge #5.23)
This concrete encased stone arch culvert carries the former Chicago, Burlington & Quincy Railroad over Batavia Creek south of Batavia
Batavia, Kane County, Illinois
Owner: BNSF Railway
Status: In Use
Built c. 1850
by
Unknown
for
Chicago, Burlington & Quincy Railroad
Design:
10' stone arch culvert
Description:
Concrete encased stone arch culvert over Batavia Creek
Significance:
BNSF Rathbone Avenue Bridge (Aurora)
/129117.JPG)
BNSF Rathbone Avenue Bridge (Aurora)
(Chicago, Burlington and Quincy Railroad Bridge #38.83)
This concrete slab bridge carries the former Chicago, Burlington & Quincy Railroad over Rathbone Avenue in Aurora
Owner: BNSF Railway
Status: In Use
Built 1921
by
Chicago, Burlington & Quincy Railroad
Design:
2-25' and 2-10' concrete slabs
Description:
Concrete slab bridge over Rathbone Avenue
Significance:
St. Charles Railroad Bridge
St. Charles Railroad Bridge
(Chicago Great Western Railway Bridge #C36.41)
This deck plate girder bridge carries the former Chicago Great Western Railway over the Fox River in St. Charles
St. Charles, Kane County, Illinois
Owner: Union Pacific Railroad
Status: Abandoned
Built 1956
by
Unknown and John P. Abrahamson Construction Company of Des Moines, Iowa
for
Chicago Great Western Railway
Design:
6-66' and 2-40' deck plate girder
Description:
Deck plate girder bridge over Fox River
Significance:
CNW Elgin Corrugated Box Company Driveway Bridge
CNW Elgin Corrugated Box Company Driveway Bridge
(Chicago & North Western Railway Bridge #601)
This abandoned steel stringer bridge carried the Chicago & North Western Railway over a driveway of the Elgin Corrugated Box Company
Owner: Union Pacific Railroad
Status: Abandoned
Built 1912
by
American Bridge Company of New York
for
Chicago & North Western Railway
Design:
20' steel stringer
Description:
Steel stringer bridge over former driveway
Significance:
UP Tyler Creek Bridge (West)
/130030.JPG)
UP Tyler Creek Bridge (West)
(Chicago & North Western Railway Bridge #355)
This small steel stringer bridge carries the former Chicago & North Western Railway over Tyler Creek on the west side of Elgin
Owner: Union Pacific Railroad
Status: In Use
Built c. 1930
by
Unknown
for
Chicago & North Western Railway
Design:
25' steel stringer
Description:
Steel stringer bridge over Tyler Creek
Significance:
BNSF West Branch Big Rock Creek Bridge
BNSF West Branch Big Rock Creek Bridge
(Chicago, Burlington and Quincy Railroad Bridge #52.53)
This through plate girder bridge carries the former Chicago, Burlington & Quincy Railroad over the West Branch of Big Rock Creek west of Big Rock
Big Rock, Kane County, Illinois
Owner: BNSF Railway
Status: In Use
Built 1960 using spans fabricated 1898 and c. 1930
by
Union Bridge Company of Athens, Pennsylvania and unknown
for
Chicago, Burlington & Quincy Railroad
Design:
100' through plate girder and 2-47' deck plate girder
Description:
Through plate girder bridge over West Branch Big Rock Creek
Significance:
South Elgin Railroad Crossing
South Elgin Railroad Crossing
(Chicago & North Western Railway Bridge #316)
This historic pony truss bridge carries the former Chicago & North Western Railway over the former Illinois Central Railroad near Stearns Road in South Elgin
South Elgin, Kane County, Illinois
Owner: Union Pacific Railroad
Status: In Use
Built 1887
by
Union Bridge Company of Buffalo, New York and Unknown
for
Chicago & North Western Railway
Design:
87' double intersection Warren pony truss
Description:
Double intersection Warren pony truss bridge over Canadian National Railway
Significance:
