Railroad Bridges in Cook County, Illinois

Cook County is located in northeast Illinois, and is the most populous county in Illinois. The seat and largest city are both Chicago.
Cities Chicago Lemont Glencoe Northbrook Evanston River Forest Arlington Heights Des Plaines Hillside Matteson Flossmoor Homewood North Riverside Lyons Melrose Park Skokie River Grove Berwyn

Random Bridges

Abandoned Lawrence Avenue Bridge (Portage Park)
Image name

Abandoned Lawrence Avenue Bridge (Portage Park)

(Chicago & North Western Railway Bridge #522)

This abandoned trough floor steel stringer bridge crosses Lawrence Avenue at Cicero Avenue

Portage Park, Chicago, Cook County, Illinois to Forest Glen, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: Abandoned

Built 1928

by

American Bridge Company of New York

for

Chicago & North Western Railway

Design:
2-36' trough floor steel stringer

Description:
Trough floor steel stringer bridge over Lawrence Avenue

Significance:

Local

CNW North Shore Channel Bridge
Image name

CNW North Shore Channel Bridge

(Chicago & North Western Railway Bridge #543 1/4)

This unusual deck plate girder bridge carries an abandoned railroad over the North Shore Channel south of Oakton Street

Skokie, Cook County, Illinois

Owner: Private Owner

Status: In Use

Built 1909

by

George W. Jackson, Inc. of Chicago, Illinois and John T. Fanning & Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
60' deck plate girder

Description:
Deck plate girder bridge over North Shore Channel

Significance:

Moderate

CTA Purple Line - Simpson Street Bridge
Image name

CTA Purple Line - Simpson Street Bridge

(Chicago, Milwaukee & St. Paul Railway Bridge #J-166)

This standard concrete slab bridge carries the CTA Purple Line over Simpson Street in Evanston

Evanston, Cook County, Illinois

Owner: Chicago Transit Authority

Status: In Use

Built 1930

by

Unknown

for

Chicago, Milwaukee, St. Paul & Pacific Railroad

Design:
2-25' concrete slabs

Description:
Concrete slab bridge over Simpson Street

Significance:

Local

CN Chicago Avenue Bridge (River Forest)
Image name

CN Chicago Avenue Bridge (River Forest)

(Soo Line Railroad Bridge #11.91)

This through plate girder bridge crosses Chicago Avenue in River Forest

River Forest, Cook County, Illinois

Owner: Canadian National Railway

Status: In Use

Built c. 1910

by

Unknown

for

Minneapolis, St. Paul & Sault Ste. Marie Railroad

Design:
42' and 2-20' through plate girders

Description:
Through plate girder bridge over Chicago Avenue

Significance:

Local

CN Dixie Highway Bridge (Homewood)
Image name

CN Dixie Highway Bridge (Homewood)

(Illinois Central Railroad Bridge #23.5)

This concrete encased beam bridge carries the Metra Electric District over Dixie Highway in Homewood

Homewood, Cook County, Illinois

Owner: Canadian National Railway

Status: In Use

Built 1923

by

Bates & Rogers Construction Company of Chicago, Illinois

for

Illinois Central Railroad

Design:
2-20' concrete encased beam and 2-12' concrete slabs

Description:
Concrete encased beam bridge over Dixie Highway

Significance:

Local

BNSF Des Plaines River Bridge (Lyons)
Image name

BNSF Des Plaines River Bridge (Lyons)

(Atchison, Topeka & Santa Fe Railway Bridge #11A)

This deck plate girder bridge carries the former Santa Fe over the Des Plaines River in Lyons

Lyons, Cook County, Illinois

Owner: BNSF Railway

Status: In Use

Built 1898

by

Unknown

for

Atchison, Topeka & Santa Fe Railway

Design:
6-52' deck plate girder and 2-30' concrete slab

Description:
Deck plate girder bridge over Des Plaines River

Significance:

Local

CTA Purple Line - Ridge Avenue Bridge
Image name

CTA Purple Line - Ridge Avenue Bridge

(Chicago, Milwaukee & St. Paul Railway Bridge #J-174)

This through plate girder bridge carries the CTA Purple Line over Ridge Avenue and Lincoln Street in Evanston

Evanston, Cook County, Illinois

Owner: Chicago Transit Authority

Status: In Use

Built 1930

by

McClintic-Marshall Corportation of Chicago, Illinois

for

Chicago, Milwaukee, St. Paul & Pacific Railroad

Design:
1-100' and 2-20' through plate girders

Description:
Through plate girder bridge over Ridge Avenue and Lincoln Street

Significance:

Local

UP Keystone Avenue Bridge (River Forest)
Image name

UP Keystone Avenue Bridge (River Forest)

(Chicago & North Western Railway Bridge #14.8)

This trough floor steel stringer bridge carries the Union Pacific West line over Keystone Avenue in River Forest

River Forest, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1914

by

Unknown

for

Chicago & North Western Railway

Design:
2-24' and 2-10' trough floor steel stringer

Description:
Trough floor steel stringer bridge over Keystone Avenue

Significance:

Local

UP Wellington Avenue Bridge (North Center)
Image name

UP Wellington Avenue Bridge (North Center)

(Chicago & North Western Railway Bridge #1301 1/2)

This through plate girder bridge carries the Union Pacific North Line over Wellington Avenue in the North Center neighborhood of Chicago

North Center, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1896

by

Lassig Bridge & Iron Works of Chicago

for

Chicago & North Western Railway

Design:
70' through plate girder

Description:
Through plate girder bridge over Wellington Avenue

Significance:

Local

CPKC Wrightwood Avenue Bridge (Logan Square)
Image name

CPKC Wrightwood Avenue Bridge (Logan Square)

(Chicago, Milwaukee & St. Paul Railway Bridge #A-20)

This decorative steel stringer bridge carries the Metra Milwaukee District North Line over Wrightwood Avenue

Logan Square, Chicago, Cook County, Illinois to Hermosa, Chicago, Illinois

Owner: Canadian Pacific Kansas City Limited

Status: In Use

Built 1939

by

Wisconsin Bridge & Iron Company of North Milwaukee, Wisconsin and L. Balkin Builder of Chicago, Illinois

for

Chicago, Milwaukee, St. Paul & Pacific Railroad

Design:
46' steel stringer and concrete slab

Description:
Steel stringer bridge over Wrightwood Avenue

Significance:

Local
